What is it about?

This app contains a wide range of structural shape sizes. A simple quick and organised way to have access of the main information needed for structural calculations from your iPhone.

Steel Profiles Catalogue

App Details

Version
1.0
Rating
NA
Size
13Mb
Genre
Productivity Utilities
Last updated
July 10, 2017
Release date
July 10, 2017
More info

App Screenshots

Steel Profiles Catalogue screenshot-0
Steel Profiles Catalogue screenshot-1
Steel Profiles Catalogue screenshot-2
Steel Profiles Catalogue screenshot-3

App Store Description

This app contains a wide range of structural shape sizes. A simple quick and organised way to have access of the main information needed for structural calculations from your iPhone.

You will find here information about their properties:

Geometry: depth & width of section, total area, shear area, web & flange thickness, radiuses, depth of straight portion of web, mass.

Structural information (strong & weak axis): second moment of area, radius of gyration, elastic & plastic section modulus.

You will be able also to calculate the beam weight and cost.
