WagoLink

Supervision application for WAGO automat. Particularly intended for supervision integrators. For research laboratory, automatisms or for teaching.

WagoLink can read one or more accessible WAGO PLC over Internet, well adapted for numerical results presentation. You must add a XML file inside the PLC webserv folder (ftp).
WagoLink questions regularly this file (2s) and show results in a specific window. This XML file must be a WagoML file, you will find a WagoML description here : http://pautex.fr/wago/wagoml.php

Elements available for dplay :
- TEXT : display only with unit.
- SLIDER : Read and set a data source.
- BUTON : Action
- DATE : Display only.
- TIME : Set and display a time data.

You can adapt this application for another PLC, which would get the same kind of net service. WagolLink is also full compatible with MBED controller.
A service computer may be necessary for wan net interface.

Development: Pautex JF, Noirel Cyril, Zander Patrick
¢ JF Pautex 2009-2017, NANCY
