BlueIOPin

BlueIOPin app allows users to connect with the BlueIO832Mini board of I-SYST Inc to control and setting pins of the BlueIO832Mini board as follows:

• Pins (D0-D5) can be individually configured as digital input/output terminal and PWM
1. Digital Input
• The app reads and displays the selected pin’s value
• Polling mode: User presses a button in the app to read a pin’s value
• Notification: The firmware automatically sends a notification to the app whenever a pin’s value change is detected
2. Digital Output
• The app controls the pin output digital value (0/1)
3. Pulse Width Modulation (PWM) signal generation
• Duty cycle (0-100%)
• Clock polarity (0-LOW, 1-HIGH)
• 3 PWM groups where each group: Output up to 4 pins with different duty cycles, and has individual frequency
• Frequency (1Hz ~ 4MHz)
