RCBController

RCBController has an interface of a gamepad, and if these buttons are pushed, it will transmit the following data by Bluetooth LE (BLE).

When you use this App, I have not specified the BLE device for reception.
If you want to use this App, please program your BLE device to be able to receive the data of BLE which this App has transmitted.


[Service & characteristic UUID to recognize]

Servie / Transmit / Receive / Vibrate Characteristic UUID:
RCB Default UUID (SBDBT, mbed etc.)
FFF0 / FFF1 / FFF2 / FFF3
SBDBT SBBLE, konashi (9600bps)
FF00 / 3012 / 3013 / FFF3
koshian (9600bps) / konashi2 (115200bps)
229BFF00-03FB-40DA-98A7-B0DEF65C2D4B
229B3012-03FB-40DA-98A7-B0DEF65C2D4B
229B3013-03FB-40DA-98A7-B0DEF65C2D4B
RFduino
2220 / 2222 / 2221
LightBlue Bean
A495FF20-C5B1-4B44-B512-1370F02D74DE
A495FF21-C5B1-4B44-B512-1370F02D74DE (Scratch1)
A495FF22-C5B1-4B44-B512-1370F02D74DE (Scratch2)
A495FF23-C5B1-4B44-B512-1370F02D74DE (Scratch3)
FemtoduinoBLE
195AE58A-437A-489B-B0CD-B7C9C394BAE4
5FC569A0-74A9-4FA4-B8B7-8354C86E45A4
21819AB0-C937-4188- B0DB-B9621E1696CD
BLESerial
569A1101-B87F-490C-92CB-11BA5EA5167C
569A2001-B87F-490C-92CB-11BA5EA5167C
569A2000-B87F-490C-92CB-11BA5EA5167C

[Transmit data format]
The 1 - 2nd byte: Button
(Right buttons)
　UP: 0x0001
　DOWN: 0x0002
　RIGHT: 0x0004
　LEFT: 0x0008
(Left buttons)
　Y button: 0x0010
　A button: 0x0020
　B button: 0x0040
　X button: 0x0100
　left center: 0x0080
(Shift buttons)
　L1: 0x0200
　L2: 0x0400
　R1: 0x0800
　R2: 0x1000
(Other)
　START: 0x0003
　SELECT: 0x000C

The 3 - 4th byte: Left analog Stick
　Left - Right: 1-255 (Neutral=128)
　Up - Down: 1-255 (Neutral=128)

The 5 - 6th byte: Right analog Stick
　Left - Right: 1-255 (Neutral=128)
　Up - Down: 1-255 (Neutral=128)

The 7 - 9th byte: Accelerator
　X axis: 1-255 (Neutral=128)
　Y axis: 1-255 (Neutral=128)
　Z axis: 1-255 (Neutral=128)

The 10th byte: Status information
　7 - 6th bit: Accelerator (0-3)
　5th bit: Left analog (0-1)
　4th bit: Right analog (0-1)
　3-1st bit: Device direction (1-4)


[Support Home page]
http://rcbcontroller.micutil.com

[BLE module]
I tested BLE modules.
mbed HRM1017: http://international.switch-science.com/catalog/1755/
mbed LPC1768: https://mbed.org/platforms/mbed-LPC1768/
(Wall Bot: http://international.switch-science.com/catalog/1346/)
RFduino: http://www.rfduino.com
SBDBT: http://www.runele.com/ca1/2/
SBDBT5V: http://www.runele.com/ca1/8/p-r-s/
(http://micono.cocolog-nifty.com/blog/sbdbthex.html)
BLESerial: http://www.robotsfx.com/robot/BLESerial.html

[Sample Movies]
https://www.youtube.com/watch?v=XCwBJUlRV8M
https://www.youtube.com/watch?v=_58DGAJdn74
https://www.youtube.com/watch?v=EeTwqm7gjw4
https://www.youtube.com/watch?v=0stL7XvlJaQ
https://www.youtube.com/watch?v=qh500FgvkLI
https://www.youtube.com/watch?v=YcgsxyYMVVo
